# Week 8

Math
First Images
Plane
Plane Images
Diffuse
Diffuse Images
Diffuse Fix
Fixed Image

### Math

• Renderer::buildPixArray()

Fixed the order of my for loops so that iteration is done from top left corner to bottom right

``` int pixIndex = 0; for( int y = 0; y < _height; y++ ) {   double nY = (y + 0.5)/h;   for( int x = 0; x < _width; x++ )   {     double nX = (x + 0.5)/w;     _pixel[pixIndex] = theTracer.Trace( nX, nY );     pixIndex++;   } }```
• Tracer::_width

I was not including the distance of the camera forward vector into the width calculation

``` _camForward = _lookat - _eye; double dist = _camForward.magnitude(); _width = dist * 2 * tan( radFOV / 2 );```
• Tracer::Trace(double nx, double ny)

Validated the calculation of my view vector. I think i was over complicating the math here which made it difficult to visualize in my head what was ACTUALLY happening. This updated version is easier to read.

``` Point3d s; s = _lookat; //move out to render plane s += _height * ( 0.5 - ny ) * _camUp; s += _width * ( 0.5 - nx ) * _camRight * -1;```
• Sphere::detectHit

My Sphere intersection calculation was wrong. I read about it in the text book: Fundementals of Computer Graphics 2nd ed. to get the correct math working

``` double a = view.dot(view); double b = 2*view.dot(eye - _position); double c = ( eye - _position ).dot( eye - _position ) - ( _radius * _radius );```

### First Images

above: one sphere with a position (-1, 0, 0)

above: two spheres intersecting

above: two spheres intersecting with color

### Plane

I got the plane intersection working. I used this siggraph reference: Ray-Plane Intersection. My first attemts were wrong. Turns out my comprehension of the paper was a bit off. I reversed my dot products.

``` Vector3d Rd = view; Normal3d Pn = _normal.getNormalized(); double t = -1; double Vd = Pn.dot( Rd ); if( Vd < 0 ) {   //normal of plane is facing camera   Point3d origin(0,0,0);   Vector3d toPlane = _position - origin;   double dist = toPlane.magnitude();   double V0 = (Pn.dot( eye ) + dist) * -1;   t = V0 / Vd; } return t; ```

### Plane Images

above: first attempt at plane intersection. incorrect dot product calculations

above: correct plane intersection calculation

### Diffuse

I built my material classes. The flat shader went pretty smooth. Getting Diffuse to look right is proving to be somewhat of a challenge.

``` double diffuse; list< Light* >::iterator iter; list< Light* > *lights = Scene::getInstance()->getLightList(); for( iter = lights->begin(); iter != lights->end(); iter++ ) {   double dotProd = (*iter)->getDirection( hit ).dot( hit.normal );   if( dotProd < 0 )     diffuse *= dotProd; } return( (_color * diffuse).clamp() ); ```

### Diffuse Images

above: hmmmmm.... first render with diffuse. Not too sure what's going on here.

### Diffuse Fix

• Backwards light vector

Recalculated so that it points towards the light

```Color3d Diffuse::getColor( const HitRecord &hit ) {   double diffuse = 0.0;   list< Light* >::iterator iter;   list< Light* > *lights = Scene::getInstance()->getLightList();   for( iter = lights->begin(); iter != lights->end(); iter++ )   {     Normal3d Nn = hit.normal;     Nn.normalize();     Normal3d Ll = (*iter)->getDirection( hit );     Ll.normalize();     double dotProd = Nn.dot( Ll );     if( dotProd > 0 )       diffuse += dotProd; } Color3d result = _color * diffuse; result.clamp(); return( result ); }```
